The Rhino 4134 is a tractor model with a rated power output of 30 hp, categorising it as a lighter model in its class. Manufactured between 1995 and 1999, it features a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and an 8-speed gearbox. The Rhino 4134 has an operating weight of 1428 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1428 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
30 hp
Recorded weight
1428 kg
Transmissions
8-speed gear
Production years
1995-1999
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerRhinoReference
Compact Utility tractorReference
Built in ChinaReference
Four-wheel driveReference
Power steeringReference
Mechanical drum brakesReference
Two-post fixed ROPS.Reference
Engine
2.2L 3-cyl dieselReference
Engine29.8 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Power29.8 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutch228.6mm dry discReference
PTO & Hydraulics
PTO (claimed)22.4 kWReference
Typeopen centerReference
Valves2Reference
Pump flow19.9 lpmReference
Steering flow12.9 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)816 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase178 cmReference
Weight1428 kgReference
Front tire7.5x16Reference
Rear tire11.2x24Reference
Standard tires (ag)Front: 7.5x16. Rear: 11.2x24Reference
Length302 cmReference
Width170 cmReference
Height (steering wheel)137 cmReference
Height (ROPS)226 cmReference
Clearance (front axle)30 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
