Search/Tractor/RK Tractors/RK19H

Tractor · 2017Unverified

RK Tractors RK19H

Name: RK Tractors RK19H
Brand: RK Tractors

RK Tractors RK19H — Sub-Compact Utility tractor · 19 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

19 hp

Weight

650 kg

Hover a source tag to verify

Overview

DistributorRK Tractors (a part of Rural King)Reference

ManufacturerTYMReference

Sub-Compact Utility tractorReference

Original price was $8,299 in 2017Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS.Reference

Engine

Yanmar 1.0L 3-cyl dieselReference

Fuel tank25.0 LReference

Engine (gross)14.2 kWReference

Yanmar 3TNV74FReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.0 LReference

Bore/Stroke74 x 77 mmReference

Power (gross)14.2 kWReference

Fuel systemindirect injectionReference

Rated RPM3000Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)11.0 kWReference

Pump flow15.8 lpmReference

Total flow26.4 lpmReference

Steering flow8.0 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)498 kgReference

Rear lift (at 24"/610mm)307 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTO Type2500Reference

Dimensions

Wheelbase134 cmReference

Weight650 kgReference

Front tire16x6.50-8Reference

Rear tire24x12-12Reference

Standard tires (ag)Front: 16x6.50-8. Rear: 24x12-12Reference

Lawn/turf front16x7.5-8Reference

Lawn/turf rear24x12-12Reference

Length239 cmReference

Width113 cmReference

Height (ROPS)219 cmReference

Ground clearance21 cmReference
