Tractor · 2021Unverified
RK Tractors RK25H
RK Tractors RK25H — Sub-Compact Utility tractor · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
853 kg
Hover a source tag to verify
Overview
DistributorRK Tractors (a part of Rural King)Reference
ManufacturerTYMReference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with heater.Reference
Engine
Yanmar 1.3L 3-cyl dieselReference
Engine18.4 kWReference
Yanmar 3TNV80FReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke80 x 84 mmReference
Power18.4 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.7 LReference
Coolant capacity3.6 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)13.6 kWReference
Hydraulic system22.0 LReference
Typeopen centerReference
Capacity22.0 LReference
Pump flow15.8 lpmReference
Total flow26.3 lpmReference
Steering flow10.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift695 kgReference
Rear lift (at 24"/610mm)499 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Capacities
Fuel25.0 LReference
Dimensions
Wheelbase154 cmReference
Weight853 kgReference
Weight123 kgReference
Weight489 kgReference
Length273 cmReference
Width134 cmReference
Height (ROPS)228 cmReference
Ground clearance19 cmReference
RK Tractors RK25H attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount RK Tractors M60Reference
Type3-bladeReference
Cutting width152 cmReference
Cut height2 to 10 cmReference
RK Tractors BH6.7 Backhoe
Backhoe typeRK Tractors BH6.7 BackhoeReference
Transport height205 cmReference
Bucket width15 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
2-Foot flat digging depth204 cmReference
Reach from pivot299 cmReference
Loading height160 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1290 kgReference
Dipperstick force850 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
