Tractor · 2017Unverified
RK Tractors RK37H
RK Tractors RK37H — Compact Utility tractor · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
1408 kg
Hover a source tag to verify
Overview
DistributorRK Tractors (a part of Rural King)Reference
ManufacturerTYMReference
Compact Utility tractorReference
Original price was $18,999 in 2017Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Variants
RK37Sshuttle ROPSReference
RK37Hhydrostatic ROPSReference
RK37SCshuttle cabReference
RK37HChydrostatic cabReference
Engine
Yanmar 1.6L 3-cyl dieselReference
Fuel tank34.1 LReference
Engine (gross)27.9 kWReference
Yanmar 3TNV88-CRReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke86 x 90 mmReference
Power (gross)27.9 kWReference
Fuel systemcommon rail direct injectionReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)21.5 kWReference
Valves1Reference
Pump flow24.2 lpmReference
Total flow41.6 lpmReference
Steering flow17.4 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1200 kgReference
Rear lift (at 24"/610mm)800 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Mid PTOOptionalReference
Dimensions
Wheelbase167 cmReference
Weight1408 kgReference
Front tire7-16Reference
Rear tire11.2x24Reference
Weight607 kgReference
Standard tires (ag)Front: 7-16. Rear: 11.2x24Reference
Lawn/turf front28x8.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front10-16.5Reference
Industrial rear43x16-20Reference
Length320 cmReference
Width135 cmReference
Height (ROPS)240 cmReference
Ground clearance32 cmReference
RK Tractors RK37H attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
RK Tractors BH7.5 Backhoe
Backhoe typeRK Tractors BH7.5 BackhoeReference
Transport height216 cmReference
Bucket width22 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
2-Foot flat digging depth231 cmReference
Reach from pivot313 cmReference
Loading height228 cmReference
Bucket Rotation149°Reference
Swing Arc180°Reference
Bucket force2065 kgReference
Dipperstick force1147 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
