Tractor · 2017Unverified

RK Tractors RK55H

Name: RK Tractors RK55H
Brand: RK Tractors

RK Tractors RK55H — Compact Utility tractor · 55 hp. Reference specifications; pending source verification.

The RK Tractors RK55H is a compact tractor with a rated output of 55 hp, produced in 2017. It features a 4-cylinder turbocharged diesel liquid-cooled engine, which powers the four-wheel drive system through a hydrostatic transmission. The tractor has a listed weight of 1730 kg and is suited to tasks on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Max power

55.1 hp

Weight

1730 kg

Catalogue coverage

Variants represented

Richest spec table

111 rows

Recorded power

55 hp

Recorded weight

1730 kg

Transmissions

hydrostatic

Production years

2017-2017

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorRK Tractors (a part of Rural King)Reference

ManufacturerTYMReference

Compact Utility tractorReference

Original price was $23,799 in 2017Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS.Reference

Variants

RK55Sshuttle ROPSReference

RK55Hhydrostatic ROPSReference

RK55SCshuttle cabReference

RK55HChydrostatic cabReference

Engine

Yanmar 2.1L 4-cyl dieselReference

Fuel tank64.3 LReference

Engine (gross)41.1 kWReference

Yanmar 4TNV86T-CRReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.1 LReference

Bore/Stroke86 x 90 mmReference

Power (gross)41.1 kWReference

Fuel systemcommon rail direct injectionReference

Rated RPM2800Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders4 cylindersReference

Rated engine speed2,800 rpmReference

Injection pump typeCommon Rail Direct InjectionReference

AspirationTurbochargedReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

forward and reverse options3 RangeReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)31.5 kWReference

Valves2Reference

Pump flow36.0 lpmReference

Total flow54.9 lpmReference

Steering flow18.9 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift (at ends)1503 kgReference

Rear lift (at 24"/610mm)1335 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTOOptionalReference

Dimensions

Wheelbase193 cmReference

Weight1730 kgReference

Front tire9.5x16Reference

Rear tire14.9x24Reference

Weight680 kgReference

Standard tires (ag)Front: 9.5x16. Rear: 14.9x24Reference

Lawn/turf front12x16.5Reference

Lawn/turf rear16.9x24Reference

Industrial front12x16.5Reference

Industrial rear16.9x24Reference

Length358 cmReference

Width162 cmReference

Height (ROPS)259 cmReference

Ground clearance35 cmReference

RK Tractors RK55H attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps70Reference

Battery volts12Reference

Alternator size12V 70AReference

Attachment overview

Front-end loaderReference

BackhoeReference

RK Tractors BH8.0 Backhoe

Backhoe typeRK Tractors BH8.0 BackhoeReference

Transport height231 cmReference

Bucket width22 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

2-Foot flat digging depth262 cmReference

Reach from pivot341 cmReference

Loading height234 cmReference

Bucket Rotation151°Reference

Swing Arc180°Reference

Bucket force2011 kgReference

Dipperstick force1221 kgReference

General

Make & ModelYanmar @ 4TNV86T-CRReference

Cruise controlTRUEReference

Differential lockTRUEReference

SCV controlJoystickReference

Capacities

Capacity127.6 cu. in.Reference

Power

Max Power55.1 hpReference

PTO

PTO Power42.2 hpReference

Rear PTO PowerTRUEReference

Rear PTO ControlElectric/HydroReference

Rear PTO RPM540 rpmReference

Steering & brakes

BrakesWet DiscReference

Steering typeHydrostatic power steeringReference

Hydraulics

Pump Rated Output (total)14.5 gpmReference

Hydraulics TypeOpen CenterReference

Remote Valves2 setsReference

Steering & Implements flow5 gpm (9.5 gpm)Reference

Rear Hitch category (SAE designation)3-Point Hitch | Category IReference

Rear Hitch maximum lift capacity1,503.2 kgReference

Dimensions & weight

Height Over ROPS259.1 cmReference

Overall Length358.9 cmReference

Overall Width162.1 cmReference

Overall weight1,730 kgReference

Operator station

Cab AvailabilityFALSEReference

Cab Air conditioning, temperature differentialFALSEReference

Seat SuspensiontrueReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
