Tractor · 2017Unverified
RK Tractors RK55SC
RK Tractors RK55SC — Compact Utility tractor · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
1915 kg
Hover a source tag to verify
Overview
DistributorRK Tractors (a part of Rural King)Reference
ManufacturerTYMReference
Compact Utility tractorReference
Original price was $25,799 in 2017Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning and audio system.Reference
Variants
RK55Sshuttle ROPSReference
RK55Hhydrostatic ROPSReference
RK55SCshuttle cabReference
RK55HChydrostatic cabReference
Engine
Yanmar 2.1L 4-cyl dieselReference
Fuel tank64.3 LReference
Engine (gross)41.1 kWReference
Yanmar 4TNV86T-CRReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.1 LReference
Bore/Stroke86 x 90 mmReference
Power (gross)41.1 kWReference
Fuel systemcommon rail direct injectionReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears16 forward and reverseReference
Four synchronized gears (1-4) in four ranges with mechanical shuttle.Reference
PTO & Hydraulics
PTO (claimed)33.5 kWReference
Valves2Reference
Pump flow36.0 lpmReference
Total flow54.9 lpmReference
Steering flow18.9 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1503 kgReference
Rear lift (at 24"/610mm)1335 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase193 cmReference
Weight1915 kgReference
Front tire9.5x16Reference
Rear tire14.9x24Reference
Weight680 kgReference
Standard tires (ag)Front: 9.5x16. Rear: 14.9x24Reference
Lawn/turf front12x16.5Reference
Lawn/turf rear16.9x24Reference
Industrial front12x16.5Reference
Industrial rear16.9x24Reference
Length358 cmReference
Width162 cmReference
Height (cab)252 cmReference
Ground clearance35 cmReference
RK Tractors RK55SC attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps70Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
RK Tractors BH8.0 Backhoe
Backhoe typeRK Tractors BH8.0 BackhoeReference
Transport height231 cmReference
Bucket width22 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
2-Foot flat digging depth262 cmReference
Reach from pivot341 cmReference
Loading height234 cmReference
Bucket Rotation151°Reference
Swing Arc180°Reference
Bucket force2011 kgReference
Dipperstick force1221 kgReference
Speeds
Reverse speeds are 15% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
