Lawn Tractor · 1999Unverified
Sabre 1438HS
Sabre 1438HS — Lawn tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
175 kg
Hover a source tag to verify
Overview
ManufacturerSabre (a part of John Deere)Reference
Lawn tractorReference
Built in Greeneville, Tennessee, USAReference
Original price was $1,629 in 1999Reference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
14.5HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank4.7 LReference
Briggs & Stratton IntekReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)10.8 kWReference
Air cleanerpaper with foamReference
Idle RPM1750-3300Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K51Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Wheelbase113 cmReference
Weight175 kgReference
Front tire15x6.5-6Reference
Rear tire20x8-8Reference
Lawn/turf front15x6.5-6Reference
Lawn/turf rear20x8-8Reference
Length152 cmReference
Width91 cmReference
Height (steering wheel)98 cmReference
Sabre 1438HS attachments
38" mid-mount mower deckReference
snowblowerReference
bladeReference
1438HS Serial Numbers
Location:Serial number decal on top of the rear fender deck, below the seat.Reference
1999GX1438B 010001Reference
2000GX1438B 020001Reference
2001GX1438B 120228Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemunregulatedReference
Charging amps4Reference
Battery CCA230Reference
Battery volts12Reference
Battery GroupBCI U1Reference
Attachment overview
38" mid-mount mower deckReference
SnowblowerReference
BladeReference
38" Mower deck
Typemid-mount SabreReference
Type2-blade with manual liftReference
Cutting width96 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
