Lawn Tractor · 1998Unverified

Sabre 1642GS

Name: Sabre 1642GS
Brand: Sabre

Sabre 1642GS — Lawn tractor · 16 hp. Reference specifications; pending source verification.

The Sabre 1642GS lawn tractor model is rated at 16 hp, positioning it in the middle of its class in terms of power. Manufactured in 1998, this model is powered by a 1-cylinder petrol air-cooled engine, which drives through a two-wheel drive system with a 5-speed gearbox. Weighing 179 kg, the Sabre 1642GS is suitable for tasks involving areas of approximately up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

16 hp

Weight

179 kg

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

16 hp

Transmissions

5-speed gear

Production years

1998-1998

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSabre (a part of John Deere)Reference

Lawn tractorReference

Built in Greeneville, Tennessee, USAReference

Two-wheel driveReference

Manual steeringReference

Disc brakesReference

Open operator station.Reference

Engine

16HP Briggs & Stratton 465cc 1-cyl gasolineReference

Fuel tank4.7 LReference

Briggs & Stratton 28Q777Reference

gasolineReference

1-cylinderReference

air-cooled vertical-shaftReference

Displacement28.4 ciReference

Bore/Stroke87 x 78 mmReference

Power (gross)11.9 kWReference

Air cleanerpaper and foamReference

Idle RPM1750-3300Reference

StarterelectricReference

Starter volts12Reference

Transmission

5-speed gearReference

TransmissionDana 4360Reference

Typebelt-driven gearReference

Gears5 forward and 1 reverseReference

PTO & Hydraulics

Mid PTOindependentReference

ClutchmanualReference

Dimensions

Wheelbase113 cmReference

Weight179 kgReference

Front tire15x6.50-6Reference

Rear tire20x8.0-8Reference

Lawn/turf front15x6.50-6Reference

Lawn/turf rear20x8.0-8Reference

Length152 cmReference

Width91 cmReference

Height (steering wheel)98 cmReference

Sabre 1642GS attachments

42" mid-mount mower deckReference

1642GS Serial Numbers

Location:Serial number decal on the rear fender deck, under the tractor's seat.Reference

Electrical

GroundnegativeReference

Charging amps3Reference

Battery CCA230Reference

Battery volts12Reference

Battery GroupU1Reference

42" Mower deck

Typemid-mount Sabre BG10109Reference

Type2-blade with manual liftReference

Cutting width106 cmReference

Cut height2 to 10 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
