Lawn Tractor · 2000Unverified
Sabre 2354HV
Sabre 2354HV — Garden Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
272 kg
Hover a source tag to verify
Overview
ManufacturerSabre (a part of John Deere)Reference
Garden tractorReference
FactoriesHoricon, Wisconsin, USAReference
FactoriesGreeneville, Tennessee, USAReference
Original price was $4,099 in 2002Reference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
23HP Kohler 673cc 2-cyl gasolineReference
Fuel tank11.4 LReference
Kohler CV23SReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement41.1 ciReference
Power17.2 kWReference
Starter volts12Reference
Oil capacity1.9 LReference
Sparkplug gap0.762 mmReference
Transmission
hydrostaticReference
TransmissionTuff Torq K66CReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typesleeve hitchReference
Front PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase123 cmReference
Weight272 kgReference
Front tire16x6.50-8Reference
Rear tire23x12.00-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x12.00-12Reference
Length183 cmReference
Height115 cmReference
Sabre 2354HV attachments
54" mid-mount mower deckReference
snowblowerReference
bladeReference
2354HV Serial Numbers
2000M0 010001Reference
2001M0 030001Reference
2002GX 010001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
54" mid-mount mower deckReference
SnowblowerReference
BladeReference
54" Mower deck
Typemid-mount SabreReference
Type3-blade with manual liftReference
Cutting width137 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
