Tractor · 1958Unverified
SAME 240
SAME 240 · 42 hp. Reference specifications; pending source verification.
The SAME 240 is a compact tractor rated at 42 hp, featuring a 2-cylinder diesel air-cooled engine. Manufactured from 1958 to 1963, it is equipped with a 6-speed gearbox and mechanical front-wheel drive. The listed weight of the tractor is 1826 kg. Its intended application is for jobs involving approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
1826 kg
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
42 hp
Recorded weight
1826 kg
Transmissions
6-speed
Production years
1958-1963
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Built in ItalyReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
SteeringmechanicalReference
Drum brakesReference
Engine
SAME 2.5L 2-cyl dieselReference
Fuel tank50.0 LReference
Engine31.3 kWReference
SAME DA 1152Reference
dieselReference
2-cylinderReference
air-cooledReference
Displacement2.5 LReference
Bore/Stroke115 x 120 mmReference
Power31.3 kWReference
Rated RPM2000Reference
Starter volts12Reference
Transmission
6-speedReference
Transmissiongear/creeperReference
Gears6 forward and 1 reverseReference
Dimensions
Weight1826 kgReference
Front tire6.00-16Reference
Rear tire11-28Reference
Ag front6.00-16Reference
Ag rear11-28Reference
Ag rear12-28Reference
Ag front7.50-20 (4WD)Reference
Ag rear10-28 (4WD)Reference
Ag rear11-28 (4WD)Reference
Length278 cmReference
Length290 cmReference
Width160 cmReference
Height147 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
