Tractor · 1993Unverified
SAME Argon 50
SAME Argon 50 — Argon Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
4277 to 4740 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Four-post ROPS.Reference
Variants
Argon F 55orchardReference
554-50 Cronosimilar Lamborghini modelReference
H-305 XEsimilar Hurlimann modelReference
5650similar AGCO Allis modelReference
Engine
SAME 3.0L 3-cyl dieselReference
Fuel tank57.9 LReference
Engine37.0 kWReference
SAME 1000.3 AReference
dieselReference
3-cylinderReference
air-cooledReference
Displacement3.0 LReference
Bore/Stroke105 x 115 mmReference
Power37.0 kWReference
Rated RPM2350Reference
Starter volts12Reference
Transmission
8-speed mechanical shuttleReference
12-speed creeperReference
16-speedReference
24-speed creeperReference
Typemechanical shuttleReference
Gears8 forward and reverseReference
TypecreeperReference
Gears12 forward and reverseReference
Gears16 forward and 8 reverseReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Valves2 or 3Reference
Pump flow32.9 lpmReference
Rear TypeIIReference
Rear lift2960 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Rear PTO Type1000Reference
Dimensions
2WD Wheelbase197 cmReference
4WD Wheelbase192 cmReference
Weight4277 to 4740 poundsReference
Front tire6.50-16Reference
2WD Rear tire380/70R28Reference
2WD Standard tires (ag)Front: 6.50-16. Rear: 380/70R28Reference
4WD Standard tires (ag)Front: 300/70R20. Rear: 380/70R28Reference
2WD Optional tires (ag)Front: 6.00-19. Rear: 12.4R32Reference
2WD Optional tires (ag)Front: 7.50-16. Rear: 420/70R28Reference
4WD Optional tires (ag)Front: 8.3R24. Rear: 12.4R32Reference
4WD Optional tires (ag)Front: 320/70R20. Rear: 420/70R28Reference
Length338 cmReference
Width164 cmReference
2WD Weight1940 kgReference
4WD Weight2150 kgReference
2WD Ground clearance39 cmReference
4WD Ground clearance33 cmReference
2WD Front tread122 to 152 cmReference
4WD Front tread134 to 173 cmReference
Rear tread130 to 169 cmReference
Steering wheel149 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
SAME Argon 50 Height
Hood135 cmReference
ROPS224 cmReference
Speeds
With 420/70R30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
