Tractor · 1965Unverified
SAME Atlanta 45
SAME Atlanta 45 — Utility tractor · 44 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
3483 to 3814 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Engine
SAME 3.4L 4-cyl dieselReference
Engine32.8 kWReference
SAME DA 954/VReference
dieselReference
4-cylinderReference
air-cooled V4Reference
Displacement3.4 LReference
Bore/Stroke95 x 120 mmReference
Power32.8 kWReference
Compression17:1Reference
Rated RPM1700Reference
Starter typeelectricReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Dimensions
2WD Wheelbase183 cmReference
4WD Wheelbase171 cmReference
Weight3483 to 3814 poundsReference
Front tire5.550-16Reference
2WD Rear tire10-28Reference
2WD Standard tires (ag)Front: 5.550-16. Rear: 10-28Reference
4WD Standard tires (ag)Front: 7.5-20. Rear: 10-28Reference
2WD Length278 cmReference
4WD Length278 cmReference
2WD Width149 cmReference
4WD Width160 cmReference
Height146 cmReference
2WD Weight1579 kgReference
4WD Weight1730 kgReference
2WD Ground clearance42 cmReference
4WD Ground clearance24 cmReference
2WD Front tread119 to 189 cmReference
4WD Front tread122 cmReference
2WD Rear tread119 to 189 cmReference
4WD Rear tread130 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
