Tractor · 1972Unverified
SAME Delfino 35
SAME Delfino 35 — Utility tractor · 34 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
34 hp
Weight
3086 to 3417 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
SteeringmanualReference
SteeringpowerReference
Dry disc brakesReference
Open operator station. Four-post ROPS available.Reference
Engine
SAME 1.8L 2-cyl dieselReference
Fuel tank25.0 LReference
Engine25.0 kWReference
SAME 982 LReference
dieselReference
2-cylinderReference
air-cooled inlineReference
Displacement1.8 LReference
Bore/Stroke98 x 120 mmReference
Power25.0 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2200Reference
Starter volts12Reference
Transmission
6-speedReference
12-speed creeperReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
TypecreeperReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Pressure147.1 barReference
Pump flow12.9 lpmReference
Rear TypeIReference
Rear lift1339 kgReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase170 cmReference
Weight3086 to 3417 poundsReference
Front tire6.00-16Reference
2WD Rear tire11.2/10-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 11.2/10-28Reference
4WD Standard tires (ag)Front: 7.50-18. Rear: 11.2/10-28Reference
2WD Optional tires (ag)Front: 5.00-15. Rear: 11.2/10-24Reference
2WD Optional tires (ag)Front: 6.00-16. Rear: 12.4/11-28Reference
4WD Optional tires (ag)Front: 7.50-16. Rear: 11.2/10-24Reference
2WD Length269 cmReference
4WD Length271 cmReference
Width147 cmReference
Height (hood)123 cmReference
Height (ROPS)217 cmReference
2WD Weight1399 kgReference
4WD Weight1549 kgReference
2WD Ground clearance35 cmReference
4WD Ground clearance25 cmReference
2WD Front tread123 to 183 cmReference
4WD Front tread119 cmReference
Rear tread119 to 180 cmReference
Speeds
With 11.2/10-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
