Tractor · 2004Unverified

SAME Diamond 215

Name: SAME Diamond 215
Brand: SAME

SAME Diamond 215 — Diamond Series · 227 hp. Reference specifications; pending source verification.

The SAME Diamond 215 is a tractor with a rated output of 227 hp, positioning it among the higher-powered machines in its class. Produced from 2004 to 2006, the Diamond 215 is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine. This engine powers the tractor's four-wheel drive through a powershift transmission. The Diamond 215 has a listed weight of 8410 kg, suitable for applications involving around 600-1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

227 hp

Weight

8410 kg

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

227 hp

Recorded weight

8410 kg

Transmissions

40-speed four-speed power shift

Production years

2004-2006

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSAMEReference

Row-Crop tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Trailer brakespneumaticReference

Cab standard with air-conditioning.Reference

Variants

Agrotron 215similar Deutz-Fahr modelReference

Engine

Deutz 7.1L 6-cyl dieselReference

Fuel tank360.0 LReference

Fuel tank550.0 LReference

Engine (gross)169.3 kWReference

Engine (net)157.3 kWReference

Deutz BF6M 1013 ECPReference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement7.1 LReference

Bore/Stroke108 x 130 mmReference

Rated Power (net)157.3 kWReference

Rated Power (gross)169.3 kWReference

Air cleanerdryReference

Rated RPM2350Reference

Torque865.1 NmReference

Torque RPM1600Reference

Starter volts12Reference

Transmission

40-speed four-speed power shiftReference

Typefour-speed power shiftReference

Gears40 forward and reverseReference

Clutchhydraulic wet discReference

Four power shift gears in six ranges with power shuttle.Reference

PTO & Hydraulics

Typevariable displacement load-sensingReference

Pump flow120.0 lpmReference

Rear lift10501 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540E/1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase308 cmReference

Weight8410 kgReference

Rear tire710/70R42Reference

Ag rear710/70R42Reference

Length560 cmReference

Width275 cmReference

Height (cab)325 cmReference

Ground clearance59 cmReference

Front tread180 to 199 cmReference

Rear tread180 to 199 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
