Tractor · 2022Unverified
SAME Dorado 115
SAME Dorado 115 — Dorado Series · 110 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
110 hp
Weight
7882 to 9281 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Cab standard with available air-conditioning.Reference
Engine
SDF 3.9L 4-cyl dieselReference
Fuel tank95.0 LReference
Fuel tank115.1 LReference
Exhaust fluid (DEF)12.9 LReference
Engine (gross)82.0 kWReference
Engine (max)94.0 kWReference
SDF FARMotion 45Reference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke103 x 116 mmReference
EmissionsStage VReference
Rated Power (gross)82.0 kWReference
Maximum Power (gross)94.0 kWReference
Rated RPM2200Reference
Torque471.9 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
continuously-variable transmissionReference
Typecontinuously-variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
CVT Typeclosed centerReference
Pump flow54.1 lpmReference
Pump flow64.0 lpmReference
CVT Pump flow84.0 lpmReference
CVT Pump flow99.9 lpmReference
Rear TypeIIReference
Rear lift3000 kgReference
Rear lift3600 kgReference
CVT Rear lift4310 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase227 cmReference
Weight7882 to 9281 poundsReference
Length406 cmReference
Width180 cmReference
Height (cab)257 cmReference
Ground clearance40 cmReference
3575 kgReference
CVT4209 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
CVT Charging amps170Reference
Battery volts12Reference
Capacities
Max capacity5200 kgReference
CVT Max capacity5800 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
