Tractor · 2014Unverified

SAME Dorado 90.4

Name: SAME Dorado 90.4
Brand: SAME

SAME Dorado 90.4 — Dorado Series · 84 hp. Reference specifications; pending source verification.

The SAME Dorado 90.4 is a tractor model rated at 84 hp, positioning it within the middle of its class in terms of power output. Manufactured from 2014 to 2022, this model features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, which drives four-wheel drive via a powershift transmission. The listed weight for the SAME Dorado 90.4 is 3299 kg, and it is suited to tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

84 hp

Weight

3299 kg

Catalogue coverage

Variants represented

Richest spec table

56 rows

Recorded power

84 hp

Recorded weight

3299 kg

Transmissions

30-speed partially synchronized

Production years

2014-2022

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSAMEReference

Utility tractorReference

Two- or four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Cab standard with available air-conditioning.Reference

Engine

SDF 3.9L 4-cyl dieselReference

Fuel tank99.9 LReference

Engine (gross)62.6 kWReference

Engine (max)65.6 kWReference

SDF FARMotionReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke103 x 116 mmReference

EmissionsStage IIIBReference

Rated Power (gross)62.6 kWReference

Maximum Power (gross)65.6 kWReference

Rated RPM2200Reference

Torque353.9 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Transmission

30-speed partially synchronizedReference

45-speed three-speed power shiftReference

Typepartially synchronizedReference

Gears30 forward and 15 reverseReference

Five synchronized gears in three ranges with mechanical shuttle and creeper range.Reference

Typethree-speed power shiftReference

Gears45 forward and reverseReference

Five synchronized gears in three ranges with three-speed power shift and power shuttle.Reference

PTO & Hydraulics

Typeopen centerReference

Pump flow54.1 lpmReference

Rear TypeIIReference

Rear lift3000 kgReference

Rear lift3600 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540 (1.375)Reference

Rear PTO Type540/1000 (1.375)Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

2WD Wheelbase227 cmReference

4WD Wheelbase223 cmReference

Weight3299 kgReference

Length356 cmReference

Width200 cmReference

Height (cab)248 cmReference

Front tread145 to 184 cmReference

Rear tread150 to 189 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
