Tractor · 2022Unverified

SAME Dorado 95

Name: SAME Dorado 95
Brand: SAME

SAME Dorado 95 — Dorado Series · 90 hp. Reference specifications; pending source verification.

The SAME Dorado 95 is a tractor with a rated output of 90 hp, positioning it in the middle of its class in terms of power. It was manufactured in 2022. The tractor is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, which drives through four-wheel drive with a continuously variable transmission. It weighs between 7882 and 9281 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

90 hp

Weight

7882 to 9281 pounds

Catalogue coverage

Variants represented

Richest spec table

70 rows

Recorded power

90 hp

Transmissions

30-speed partially synchronized

Production years

2022-2022

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSAMEReference

Utility tractorReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Cab standard with available air-conditioning.Reference

Engine

SDF 3.9L 4-cyl dieselReference

Fuel tank95.0 LReference

Fuel tank115.1 LReference

Exhaust fluid (DEF)12.9 LReference

Engine (gross)67.1 kWReference

Engine (max)70.8 kWReference

SDF FARMotion 45Reference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke103 x 116 mmReference

EmissionsStage VReference

Rated Power (gross)67.1 kWReference

Maximum Power (gross)70.8 kWReference

Rated RPM2200Reference

Torque389.2 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Transmission

30-speed partially synchronizedReference

45-speed three-speed power shiftReference

continuously-variable transmissionReference

Typepartially synchronizedReference

Gears30 forward and 15 reverseReference

Five synchronized gears in three ranges with mechanical shuttle and creeper range.Reference

Typethree-speed power shiftReference

Gears45 forward and reverseReference

Five synchronized gears in three ranges with three-speed power shift and power shuttle.Reference

Typecontinuously-variable transmissionReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Typeopen centerReference

CVT Typeclosed centerReference

Pump flow54.1 lpmReference

Pump flow64.0 lpmReference

CVT Pump flow84.0 lpmReference

CVT Pump flow99.9 lpmReference

Rear TypeIIReference

Rear lift3000 kgReference

Rear lift3600 kgReference

CVT Rear lift4310 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540 (1.375)Reference

Rear PTO Type540/1000 (1.375)Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase227 cmReference

Weight7882 to 9281 poundsReference

Length406 cmReference

Width180 cmReference

Height (cab)257 cmReference

Ground clearance40 cmReference

3575 kgReference

CVT4209 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

CVT Charging amps170Reference

Battery volts12Reference

Capacities

Max capacity5200 kgReference

CVT Max capacity5800 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
