Tractor · 1989Unverified
SAME Explorer II 70
SAME Explorer II 70 — Explorer II Series · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
6239 to 6702 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with heat. Air-conditioning optional.Reference
Variants
5670similar AGCO Allis modelReference
Engine
SAME 4.0L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine51.0 kWReference
SAME 1000.4 AReference
dieselReference
4-cylinderReference
air-cooled inlineReference
Displacement4.0 LReference
Bore/Stroke105 x 115 mmReference
Power51.0 kWReference
Air cleanerdryReference
Rated RPM2350Reference
Starter volts12Reference
Transmission
15-speed synchronizedReference
20-speed synchronizedReference
30-speed two-speed power shiftReference
40-speed two-speed power shiftReference
TypesynchronizedReference
Gears15 forward and reverseReference
Clutchhydraulic dry discReference
Gears20 forward and reverseReference
TransmissionSyncro PowerReference
Typetwo-speed power shiftReference
Gears30 forward and reverseReference
Gears40 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow34.8 lpmReference
Rear TypeIIReference
Rear lift3430 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2083Reference
Engine RPM540E@1743Reference
Engine RPM1000@2286Reference
Engine RPM1000E@1913Reference
Dimensions
2WD Wheelbase235 cmReference
4WD Wheelbase228 cmReference
Weight6239 to 6702 poundsReference
Front tire9.00-16Reference
2WD Rear tire16.9/14-30Reference
2WD Standard tires (ag)Front: 9.00-16. Rear: 16.9/14-30Reference
4WD Standard tires (ag)Front: 12.4/11-24. Rear: 16.9/14-30Reference
2WD Optional tires (ag)Front: 9.00-16. Rear: 13.6/12-36Reference
4WD Optional tires (ag)Front: 13.6/12-24. Rear: 13.6/12-36Reference
2WD Length363 cmReference
4WD Length373 cmReference
Width197 cmReference
Height (hood)155 cmReference
Height (cab)249 cmReference
2WD Weight2830 kgReference
4WD Weight3040 kgReference
2WD Ground clearance49 cmReference
4WD Ground clearance40 cmReference
Front tread150 to 199 cmReference
Rear tread150 to 199 cmReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
