Tractor · 1989Unverified
SAME Explorer II 90
SAME Explorer II 90 — Explorer II Series · 87 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
87 hp
Weight
6791 to 7563 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Two- or four-wheel driveReference
Engine
SAME 4.0L 4-cyl dieselReference
Fuel tank110.1 LReference
Engine65.0 kWReference
SAME 1000.4 ATReference
turbocharged dieselReference
4-cylinderReference
air-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 115 mmReference
Power65.0 kWReference
Air cleanerdryReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
30-speed two-speed power shiftReference
40-speed two-speed power shiftReference
TransmissionSyncro PowerReference
Typetwo-speed power shiftReference
Gears30 forward and reverseReference
Gears40 forward and reverseReference
PTO & Hydraulics
Pump flow42.0 lpmReference
Rear lift3450 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase231 cmReference
Weight6791 to 7563 poundsReference
Front tire10.00-16Reference
2WD Rear tire16.9/14-34Reference
2WD Standard tires (ag)Front: 10.00-16. Rear: 16.9/14-34Reference
4WD Standard tires (ag)Front: 14.9/13-24. Rear: 16.9/14-34Reference
2WD Optional tires (ag)Front: 10.00-16. Rear: 13.6/12-38Reference
4WD Optional tires (ag)Front: 12.4/11-28. Rear: 13.6/12-38Reference
Length408 cmReference
Height262 cmReference
2WD Weight3080 kgReference
4WD Weight3430 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
