SAME Explorer3 105
SAME Explorer3 105 — Explorer3 Series · 102 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
102 hp
Weight
8018 to 10185 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Trailer brakespneumaticReference
Cab with available air-conditioning.Reference
Engine
SAME 4.0L 4-cyl dieselReference
Fuel tank160.1 LReference
Engine (gross)76.1 kWReference
SAME 1000.4 WTIReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 116 mmReference
EmissionsStage IIIReference
Rated Power (gross)76.1 kWReference
Air cleanerdryReference
Rated RPM2300Reference
Torque375.6 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Transmission
15-speed partially synchronizedReference
40-speed two-speed power shiftReference
Typepartially synchronizedReference
Gears15 forward and reverseReference
Five synchronized gears in three ranges. Optional creeper range provides 20 speeds.Reference
TransmissionAgroshiftReference
Typetwo-speed power shiftReference
Gears40 forward and reverseReference
Five synchronized gears in four ranges with two-speed power shift. Optional power shuttle.Reference
PTO & Hydraulics
Pump flow56.0 lpmReference
Rear lift5299 kgReference
Rear lift6200 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
2WD Wheelbase240 cmReference
4WD Wheelbase237 cmReference
Weight8018 to 10185 poundsReference
Front tire380/85R24Reference
Rear tire480/85R34Reference
Standard tires (ag)Front: 380/85R24. Rear: 480/85R34Reference
Length420 cmReference
Width204 cmReference
Height (cab)278 cmReference
2WD Weight3636 kgReference
4WD Weight4619 kgReference
Ground clearance50 cmReference
Front tread163 to 213 cmReference
Rear tread159 to 213 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
