Tractor · 2004Unverified

SAME Explorer3 75

Name: SAME Explorer3 75
Brand: SAME

SAME Explorer3 75 — Explorer3 Series · 75 hp. Reference specifications; pending source verification.

The SAME Explorer3 75 is a tractor rated at 75 hp, positioning it centrally within its class in terms of power output. Manufactured from 2004 to 2007, the Explorer3 75 is equipped with a 4-cylinder diesel liquid-cooled engine, which drives four-wheel drive via a powershift transmission. The listed operating weight of the tractor ranges from 7893 to 8223 pounds. It is suitable for tasks covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

75 hp

Weight

7893 to 8223 pounds

Catalogue coverage

Variants represented

Richest spec table

60 rows

Recorded power

75 hp

Recorded weight

3580 kg

Transmissions

15-speed partially synchronized

Production years

2004-2007

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSAMEReference

Utility tractorReference

Two- or four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Trailer brakespneumaticReference

Two-post ROPS. Available cab with air-conditioning.Reference

Engine

SAME 4.0L 4-cyl dieselReference

Fuel tank160.1 LReference

Engine (gross)55.9 kWReference

Engine (net)52.9 kWReference

SAME 1000.4 WReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.0 LReference

Bore/Stroke105 x 116 mmReference

EmissionsStage IIReference

Rated Power (net)52.9 kWReference

Rated Power (gross)55.9 kWReference

Air cleanerdryReference

Rated RPM2300Reference

Torque257.6 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Transmission

15-speed partially synchronizedReference

45-speed three-speed power shiftReference

Typepartially synchronizedReference

Gears15 forward and reverseReference

Five synchronized gears in three ranges. Optional creeper range provides 20 speeds.Reference

TransmissionAgroshiftReference

Typethree-speed power shiftReference

Gears45 forward and reverseReference

Five synchronized gears in three ranges with three-speed power shift. Optional creeper range provides 60 speeds. Optional power shuttle.Reference

PTO & Hydraulics

Pump flow54.1 lpmReference

Rear lift4799 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase235 cmReference

Weight7893 to 8223 poundsReference

Front tire14.9R24Reference

4WD Rear tire16.9R34Reference

4WD Standard tires (ag)Front: 14.9R24. Rear: 16.9R34Reference

Length376 cmReference

Width195 cmReference

Height (ROPS)269 cmReference

Height (cab)262 cmReference

ROPS Weight3580 kgReference

Cab Weight3729 kgReference

Ground clearance44 cmReference

Front tread143 to 214 cmReference

Rear tread150 to 210 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
