Tractor · 2012Unverified

SAME Explorer3 90

Name: SAME Explorer3 90
Brand: SAME

SAME Explorer3 90 — Explorer3 Series · 88 hp. Reference specifications; pending source verification.

The SAME Explorer3 90 is a tractor model rated at 88 hp, positioning it centrally within its class in terms of power output. Production of this model occurred between 2012 and 2014. It features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, which powers a four-wheel drive system with a powershift transmission. The listed operating weights for this model are 6431 to 9083 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

88 hp

Weight

6431 to 9083 pounds

Catalogue coverage

Variants represented

Richest spec table

59 rows

Recorded power

88 hp

Recorded weight

2917 kg

Transmissions

15-speed partially synchronized

Production years

2012-2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerSAMEReference

Utility tractorReference

Two- or four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Trailer brakespneumaticReference

Two-post ROPS. Available cab with air-conditioning.Reference

Engine

SAME 4.0L 4-cyl dieselReference

Fuel tank160.1 LReference

Engine (gross)65.6 kWReference

SAME 1000.4 WTIReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.0 LReference

Bore/Stroke105 x 116 mmReference

EmissionsStage IIIReference

Rated Power (gross)65.6 kWReference

Air cleanerdryReference

Rated RPM2300Reference

Torque344.4 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Transmission

15-speed partially synchronizedReference

40-speed two-speed power shiftReference

Typepartially synchronizedReference

Gears15 forward and reverseReference

Five synchronized gears in three ranges. Optional creeper range provides 20 speeds.Reference

TransmissionAgroshiftReference

Typetwo-speed power shiftReference

Gears40 forward and reverseReference

Five synchronized gears in four ranges with two-speed power shift. Optional power shuttle.Reference

PTO & Hydraulics

Pump flow56.0 lpmReference

Rear lift4300 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

2WD Wheelbase234 cmReference

4WD Wheelbase236 cmReference

Weight6431 to 9083 poundsReference

Front tire320/85R24Reference

Rear tire420/85R34Reference

Standard tires (ag)Front: 320/85R24. Rear: 420/85R34Reference

Length407 cmReference

Width195 cmReference

Height (ROPS)271 cmReference

Height (cab)274 cmReference

2WD ROPS Weight2917 kgReference

4WD Cab Weight4120 kgReference

Ground clearance44 cmReference

Front tread163 to 213 cmReference

Rear tread159 to 213 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
