Tractor · 1983Unverified
SAME Laser 150
SAME Laser 150 — Laser Series · 114 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
114 hp
Weight
12125 to 12566 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Row-Crop tractorReference
Four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with available air-conditioning.Reference
Engine
SAME 6.2L 6-cyl dieselReference
Fuel tank230.1 LReference
Engine85.0 kWReference
SAME 1056 PSReference
turbocharged dieselReference
6-cylinderReference
air-cooledReference
Displacement6.2 LReference
Bore/Stroke105 x 120 mmReference
Power85.0 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
24-speed two-speed power shiftReference
16-speed creeperReference
Typetwo-speed power shiftReference
Gears24 forward and 12 reverseReference
Four gears in three ranges with shuttle and two-speed power shift.Reference
TypecreeperReference
Gears16 forward and 12 reverseReference
PTO & Hydraulics
Pump flow64.0 lpmReference
Rear TypeIII/IIReference
Controlposition and draft controlReference
Rear lift7001 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase285 cmReference
Weight12125 to 12566 poundsReference
Front tire16.9/14-30Reference
Rear tire20.8-38Reference
Standard tires (ag)Front: 16.9/14-30. Rear: 20.8-38Reference
Optional tires (ag)Front: 14.9/30-30. Rear: 18.4/15-38Reference
Length451 cmReference
Width222 cmReference
ROPS Weight5499 kgReference
Cab Weight5699 kgReference
Ground clearance53 cmReference
Front tread180 to 199 cmReference
Rear tread169 to 219 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
SAME Laser 150 Height
Hood186 cmReference
ROPS274 cmReference
Cab280 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
