Tractor · 1981Unverified
SAME Mercury 85
SAME Mercury 85 · 78 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
78 hp
Weight
6856 to 7848 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Cab optional.Reference
Engine
SAME 4.2L 4-cyl dieselReference
Fuel tank120.0 LReference
Engine61.9 kWReference
SAME 1054PReference
dieselReference
4-cylinderReference
air-cooled inlineReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power61.9 kWReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2270Reference
Starter volts12Reference
Starter power3.0 kWReference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)58.2 kWReference
Typeopen centerReference
Pump flow40.9 lpmReference
Rear TypeIIReference
Controlposition, float and depth controlReference
Rear lift3700 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase231 cmReference
Weight6856 to 7848 poundsReference
Front tire7.50-18Reference
Rear tire16.9/14-34 (2WD)Reference
Standard tires (ag)Front: 7.50-18. Rear: 16.9/14-34 (2WD)Reference
Standard tires (ag)Front: 14.9-24. Rear: 16.9/14-34 (4WD)Reference
Length363 cmReference
Length376 cmReference
Length384 cmReference
Length397 cmReference
Width193 cmReference
Width243 cmReference
2WD Clearance (front axle)53 cmReference
4WD Clearance (front axle)48 cmReference
2WD Front tread160 to 219 cmReference
4WD Front tread163 to 180 cmReference
Rear tread150 to 199 cmReference
2WD ROPS3109 kgReference
4WD ROPS3400 kgReference
4WD ROPS3270 kgReference
4WD ROPS3559 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH110Reference
SAME Mercury 85 Height
Hood160 cmReference
ROPS264 cmReference
Cab1039 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
