Tractor · 1967Unverified
SAME Minitauro 50
SAME Minitauro 50 — Utility tractor · 48 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Weight
3770 to 4255 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Two- or four-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
SAME 2.6L 3-cyl dieselReference
Fuel tank50.0 LReference
Engine35.8 kWReference
SAME 029-953Reference
dieselReference
3-cylinderReference
air-cooled inlineReference
Displacement2.6 LReference
Bore/Stroke95 x 120 mmReference
Power35.8 kWReference
Fuel systemdirect injectionReference
Compression16.5:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity9.0 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 4 reverseReference
Oil capacity38.0 LReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Dimensions
2WD Wheelbase197 cmReference
4WD Wheelbase176 cmReference
Weight3770 to 4255 poundsReference
Length305 cmReference
Width163 cmReference
Height (steering wheel)145 cmReference
Height (hood)127 cmReference
2WD Weight1710 kgReference
4WD Weight1930 kgReference
2WD Ground clearance46 cmReference
4WD Ground clearance30 cmReference
2WD Front tread119 to 189 cmReference
4WD Front tread130 to 132 cmReference
Rear tread119 to 189 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
