Tractor · Unverified
SAME Row Crop 100
SAME Row Crop 100 — Row Crop SeriesHigh-Clearance tractor · 88 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
88 hp
Weight
3402 kg
Hover a source tag to verify
Overview
ManufacturerSAMEReference
High-Clearance tractorReference
Two- or four-wheel driveReference
Differential lockmechanicalReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS.Reference
Engine
SAME 4.0L 4-cyl dieselReference
Fuel tank90.8 LReference
Engine71.6 kWReference
SAME 1000.4 WTReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 115 mmReference
Power71.6 kWReference
Air cleanerdryReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speed synchronizedReference
TypesynchronizedReference
Gears20 forward and reverseReference
Clutchhydraulic dry discReference
Five synchronized gears in four ranges with shuttle.Reference
PTO & Hydraulics
PTO (claimed)65.6 kWReference
Valves2Reference
Pump flow59.8 lpmReference
Rear TypeIIReference
Controlposition, float, and draft controlReference
Rear lift2936 kgReference
Rear lift4037 kgReference
Rear PTOliveReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase230 cmReference
Weight3402 kgReference
Front tire7.50-20Reference
2WD Rear tire13.6R38Reference
2WD Standard tires (ag)Front: 7.50-20. Rear: 13.6R38Reference
4WD Standard tires (ag)Front: 13.6R38. Rear: 13.6R38Reference
Length430 cmReference
Width218 cmReference
Height (ROPS)257 cmReference
Clearance (front axle)60 cmReference
Front tread180 to 255 cmReference
Rear tread160 to 235 cmReference
Speeds
With 13.6R38 tires. Reverse speeds are about 5% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
