Tractor · Unverified
SAME Row Crop 100.6
SAME Row Crop 100.6 — Row Crop SeriesHigh-Clearance tractor · 93 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
93 hp
Weight
10141 to 11023 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
High-Clearance tractorReference
Two- or four-wheel driveReference
Differential lockmechanicalReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
SAME 6.0L 6-cyl dieselReference
Fuel tank140.0 LReference
SAME 1000.6AReference
dieselReference
6-cylinderReference
air-cooledReference
Displacement6.0 LReference
Air cleanerdryReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speed synchronizedReference
TypesynchronizedReference
Gears20 forward and reverseReference
Clutchhydraulic dry discReference
Five synchronized gears in four ranges with shuttle.Reference
PTO & Hydraulics
PTO (claimed)69.4 kWReference
Valves2 to 4Reference
Pump flow59.8 lpmReference
Rear TypeIIReference
Rear lift3896 kgReference
Rear lift4338 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase268 cmReference
Weight10141 to 11023 poundsReference
Front tire7.50-20Reference
2WD Rear tire13.6R38Reference
2WD Standard tires (ag)Front: 7.50-20. Rear: 13.6R38Reference
4WD Standard tires (ag)Front: 13.6-38. Rear: 13.6R38Reference
4WD Standard tires (ag)Front: 12.4-46. Rear: 12.4R46Reference
Length461 cmReference
Width217 cmReference
Height (hood)190 cmReference
Height (ROPS)287 cmReference
ROPS Weight4599 kgReference
Cab Weight5000 kgReference
Ground clearance57 cmReference
Front tread154 to 214 cmReference
Rear tread144 to 224 cmReference
Speeds
With 13.6R38 tires. Reverse speeds are about 5% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
