Tractor · Unverified
SAME Row Crop 80
SAME Row Crop 80 — Row Crop SeriesHigh-Clearance tractor · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
3660 kg
Hover a source tag to verify
Overview
ManufacturerSAMEReference
High-Clearance tractorReference
Four-wheel driveReference
Differential lockmechanicalReference
Power steeringReference
Mechanical dry disc brakesReference
Four-post ROPS.Reference
Engine
SAME 4.2L 4-cyl dieselReference
Fuel tank79.9 LReference
Engine59.7 kWReference
SAME 1054PReference
dieselReference
4-cylinderReference
air-cooled inlineReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power59.7 kWReference
Fuel systemdirect-injectionReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronizedReference
14-speed creeperReference
TypesynchronizedReference
Gears8 forward and 4 reverseReference
Four gears in two ranges, plus reverse range.Reference
TypecreeperReference
Gears14 forward and 7 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure171.6 barReference
Rear TypeIIReference
Controlposition, float and lower-link draft sensingReference
Rear lift2700 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase215 cmReference
Weight3660 kgReference
Front tire13.6/12-38Reference
Rear tire13.6/12-38Reference
Standard tires (ag)Front: 13.6/12-38. Rear: 13.6/12-38Reference
Length377 cmReference
Width216 cmReference
Height (hood)161 cmReference
Height (ROPS)257 cmReference
Clearance (front axle)69 cmReference
Clearance (rear axle)67 cmReference
Front tread182 to 201 cmReference
Rear tread182 to 201 cmReference
Speeds
With 13.6/12-38 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
