Tractor · 1972Unverified
SAME Saturno 80
SAME Saturno 80 — Row-Crop tractor · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
6150 to 6746 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Row-Crop tractorReference
Two- or four-wheel driveReference
2WD SteeringmanualReference
4WD SteeringpowerReference
Mechanical dry disc brakesReference
Trailer brakeshydraulicReference
Four-post ROPS.Reference
Engine
SAME 4.2L 4-cyl dieselReference
Fuel tank79.9 LReference
Engine59.7 kWReference
SAME 1054 PReference
dieselReference
4-cylinderReference
air-cooled inlineReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power59.7 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed partially synchronizedReference
14-speed creeperReference
Typepartially synchronizedReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
Four synchronized gears in two ranges, plus reverse range.Reference
TypecreeperReference
Gears14 forward and 7 reverseReference
PTO & Hydraulics
Pump flow23.8 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2800 kgReference
Rear PTOliveReference
Clutchmechanical dry discReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase235 cmReference
Weight6150 to 6746 poundsReference
Front tire7.50-18Reference
2WD Rear tire16.9/14-34Reference
2WD Standard tires (ag)Front: 7.50-18. Rear: 16.9/14-34Reference
4WD Standard tires (ag)Front: 11.2/10-28. Rear: 16.9/14-34Reference
2WD Optional tires (ag)Front: 7.50-18. Rear: 13.6/12-38Reference
2WD Optional tires (ag)Front: 7.50-16. Rear: 16.9/14-30Reference
2WD Optional tires (ag)Front: 7.50-16. Rear: 18.4/15-30Reference
2WD Optional tires (ag)Front: 7.50-20. Rear: 16.9/14-34Reference
4WD Optional tires (ag)Front: 12.4/11-24. Rear: 13.6/12-38Reference
4WD Optional tires (ag)Front: 11.2/10-24. Rear: 16.9/14-30Reference
4WD Optional tires (ag)Front: 12.4/11-24. Rear: 18.4/15-30Reference
2WD Length389 cmReference
4WD Length399 cmReference
Width193 cmReference
2WD Weight2789 kgReference
4WD Weight3059 kgReference
2WD Ground clearance50 cmReference
4WD Ground clearance42 cmReference
2WD Front tread139 to 219 cmReference
4WD Front tread150 to 169 cmReference
Rear tread150 to 199 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
SAME Saturno 80 Height
2WD Hood136 cmReference
4WD Hood141 cmReference
ROPS246 cmReference
Speeds
With 16.9/14-34 rear tires and 25kph transmission option.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
