Tractor · 1995Unverified
SAME Silver 80
SAME Silver 80 · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
7385 to 9326 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic brakesReference
Trailer brakeshydraulicReference
Two-post ROPS. Cab optional with available air-conditioning.Reference
Engine
SAME 4.0L 4-cyl dieselReference
Fuel tank149.9 LReference
Engine59.7 kWReference
SAME 1000.4 AReference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 115 mmReference
Power59.7 kWReference
Rated RPM2500Reference
Torque275.0 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
15-speedReference
20-speedReference
45-speed partial power shiftReference
60-speed partial power shiftReference
Gears15 forward and reverseReference
Gears20 forward and reverseReference
TransmissionAgroshiftReference
Typepartial power shiftReference
Gears45 forward and reverseReference
Gears60 forward and reverseReference
Five gears in four ranges with three-speed push-button hydraulic shift.Reference
PTO & Hydraulics
Valves2 to 4Reference
Pump flow40.9 lpmReference
Pump flow48.1 lpmReference
Rear lift3600 kgReference
Rear lift47016 kgReference
Front HitchoptionalReference
Front lift1999 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/540E/1000/1000EReference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
2WD Wheelbase246 cmReference
4WD Wheelbase237 cmReference
Weight7385 to 9326 poundsReference
Front tire9.00-16Reference
2WD Rear tire16.9R34Reference
2WD Standard tires (ag)Front: 9.00-16. Rear: 16.9R34Reference
4WD Standard tires (ag)Front: 14.9R24. Rear: 16.9R34Reference
2WD Optional tires (ag)Front: 11.00-16. Rear: 480/70R34Reference
2WD Optional tires (ag)Front: 9.00-16. Rear: 13.6R38Reference
4WD Optional tires (ag)Front: 420/70R24. Rear: 480/70R34Reference
4WD Optional tires (ag)Front: 12.4R28. Rear: 13.6R38Reference
Length410 cmReference
Width183 cmReference
2WD Ground clearance51 cmReference
4WD Ground clearance44 cmReference
2WD Front tread139 to 199 cmReference
4WD Front tread150 to 210 cmReference
Rear tread150 to 235 cmReference
2WD ROPS3349 kgReference
4WD ROPS3790 kgReference
2WD Cab3600 kgReference
4WD Cab4230 kgReference
SAME Silver 80 Height
Hood147 cmReference
ROPS269 cmReference
Cab267 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
