Tractor · 1986Unverified
SAME Solar 50
SAME Solar 50 — Solar Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
4409 to 5026 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Two- or four-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Mechanical wet disc brakesReference
Four-post ROPS.Reference
Variants
550similar Lamborghini modelReference
H-351similar Hurlimann modelReference
4650similar AGCO Allis modelReference
Engine
SAME 2.7L 3-cyl dieselReference
Fuel tank54.9 LReference
Engine37.0 kWReference
SAME 983 LReference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.7 LReference
Bore/Stroke98 x 120 mmReference
Power37.0 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
12-speed synchronizedReference
16-speed creeperReference
TypesynchronizedReference
Gears12 forward and 3 reverseReference
Clutchdry discReference
TypecreeperReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
Pressure180.0 barReference
Pump flow23.8 lpmReference
Rear TypeIReference
Rear lift2370 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase209 cmReference
4WD Wheelbase206 cmReference
Weight4409 to 5026 poundsReference
Front tire6.50-16Reference
2WD Rear tire12.4/11-28Reference
2WD Standard tires (ag)Front: 6.50-16. Rear: 12.4/11-28Reference
4WD Standard tires (ag)Front: 8.00-20. Rear: 12.4/11-28Reference
2WD Optional tires (ag)Front: 6.50-16. Rear: 13.6/12-28Reference
2WD Optional tires (ag)Front: 6.50-16. Rear: 14.9/13-28Reference
2WD Optional tires (ag)Front: 6.00-19. Rear: 12.4/11-32Reference
4WD Optional tires (ag)Front: 9.5/9-20. Rear: 13.6/12-28Reference
4WD Optional tires (ag)Front: 11.2/10-20. Rear: 14.9/13-28Reference
4WD Optional tires (ag)Front: 8.3/8-24. Rear: 12.4/11-32Reference
Length314 cmReference
Length338 cmReference
Width167 cmReference
2WD Weight1999 kgReference
4WD Weight2279 kgReference
2WD Ground clearance45 cmReference
4WD Ground clearance35 cmReference
2WD Front tread122 to 163 cmReference
4WD Front tread135 to 155 cmReference
Rear tread135 to 185 cmReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
SAME Solar 50 Height
2WD Hood132 cmReference
4WD Hood130 cmReference
ROPS228 cmReference
Speeds
With 12.4/11-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
