Tractor · Unverified
SAME Solar 60C
SAME Solar 60C — Solar SeriesAgricultural Crawler tractor · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
2698 kg
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Final drivesspur gearReference
Band brakesReference
Two-post folding ROPS.Reference
Engine
SAME 3.1L 3-cyl dieselReference
Fuel tank60.2 LReference
Engine46.2 kWReference
SAME 1053PReference
dieselReference
3-cylinderReference
air-cooledReference
Displacement3.1 LReference
Bore/Stroke105 x 120 mmReference
Power46.2 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed partially synchronizedReference
Typepartially synchronizedReference
Gears8 forward and 4 reverseReference
Clutch254mm mechanical organic discReference
Four gears (1-4) in two ranges (low/high) plus reverse range.Reference
PTO & Hydraulics
Pressure175.0 barReference
Valves2Reference
Pump flow23.8 lpmReference
Rear TypeIIReference
Controltop-link draft sensingReference
Rear lift (at ends)2080 kgReference
Rear PTOindependentReference
Clutchdry discReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase137 cmReference
Weight2698 kgReference
11-inch tracksReference
Length293 cmReference
Width121 cmReference
Height (hood)114 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
SAME Solar 60C Tracks
Width27 cmReference
Width30 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
