Tractor · 1978Unverified
SAME Taurus 60
SAME Taurus 60 — Utility tractor · 58 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
58 hp
Weight
5512 to 6323 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Differential lockmechanicalReference
SteeringmanualReference
Dry disc brakesReference
Four-rops ROPS. Cab optional.Reference
Engine
SAME 3.1L 3-cyl dieselReference
Fuel tank99.9 LReference
Engine43.3 kWReference
SAME 1053PReference
dieselReference
3-cylinderReference
air-cooledReference
Displacement3.1 LReference
Bore/Stroke105 x 120 mmReference
Power43.3 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2200Reference
Starter volts12Reference
Starter power3.0 kWReference
Transmission
14-speed synchronizedReference
TypesynchronizedReference
Gears14 forward and 7 reverseReference
Clutchdry discReference
PTO & Hydraulics
Pressure171.7 barReference
Pump flow24.0 lpmReference
Rear TypeIIReference
Controllower link draft controlReference
Rear lift1959 kgReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type1000Reference
Dimensions
Wheelbase214 cmReference
Wheelbase209 cmReference
Weight5512 to 6323 poundsReference
Front tire7.50-16Reference
Rear tire14.9/13-30Reference
Standard tires (ag)Front: 7.50-16. Rear: 14.9/13-30Reference
Standard tires (ag)Front: 11.2/10-24. Rear: 14.9/13-30 (4WD)Reference
Length355 cmReference
Length357 cmReference
Width187 cmReference
Ground clearance42 cmReference
Ground clearance39 cmReference
Front tread142 to 212 cmReference
Front tread156 to 183 cmReference
Rear tread150 to 189 cmReference
2500 kgReference
2692 kgReference
2659 kgReference
2868 kgReference
Electrical
Charging systemgeneratorReference
Charging amps37.5Reference
Battery volts12Reference
SAME Taurus 60 Height
Hood144 cmReference
ROPS240 cmReference
Cab252 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
