Tractor · 2008Unverified
SAME Tiger 75
SAME Tiger 75 — Utility tractor · 72 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
72 hp
Weight
4762 to 5335 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Utility tractorReference
Built in TurkeyReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Differential lockmechanical front and rearReference
Steeringhydrostatic powerReference
Hydraulic brakesReference
Two-post foldable ROPS. Canopy avaailable.Reference
Variants
Rekord 75similar Lamborghini modelReference
Agrolux 75similar Deutz-Fahr modelReference
Tiger 75similar SAME modelReference
Engine
SAME 3.0L 3-cyl dieselReference
Fuel tank70.0 LReference
Engine (gross)53.7 kWReference
Engine (net)51.5 kWReference
SAME 1000.3Reference
turbocharged intercooled dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke105 x 116 mmReference
EmissionsTier IIIReference
Rated Power (net)51.5 kWReference
Rated Power (gross)53.7 kWReference
Air cleanerdry with safety cartridgeReference
Rated RPM2200Reference
Idle RPM750-2350Reference
Torque265.1 NmReference
Torque RPM1600Reference
Starter volts12Reference
Oil capacity5.8 LReference
Transmission
12-speed partially synchronizedReference
Typepartially synchronizedReference
Gears12 forward and 3 reverseReference
Clutchsingle dry discReference
Four gears (1-4) plus reverse (R) in three ranges (L/M/V). Gear shifts in range are synchronized.Reference
PTO & Hydraulics
Typeopen centerReference
Valves2 to 4Reference
Pump flow32.9 lpmReference
Steering flow17.0 lpmReference
Rear TypeIIReference
Rear lift (at ends)3000 kgReference
Rear PTOindependentReference
Clutchdry mechanicalReference
Rear PTO Type540/540E (1.375)Reference
Dimensions
Wheelbase203 cmReference
Wheelbase197 cmReference
Weight4762 to 5335 poundsReference
Rear tire16.9R30Reference
Ag rear16.9R30Reference
Length331 cmReference
Width198 cmReference
Height (steering wheel)154 cmReference
Height (hood)150 cmReference
Weight2160 kgReference
Weight2419 kgReference
Ground clearance40 cmReference
Front tread173 cmReference
Front tread175 cmReference
Rear tread183 cmReference
Speeds
With 16.9R30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
