Tractor · Unverified
SAME Vigneron 60
SAME Vigneron 60 — Vigneron SeriesOrchard/Vineyard tractor · 58 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
58 hp
Weight
4056 to 4519 pounds
Hover a source tag to verify
Overview
ManufacturerSAMEReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Differential lockmechanicalReference
SteeringmanualReference
SteeringpowerReference
Mechanical wet disc brakesReference
Open operator station.Reference
Engine
SAME 3.1L 3-cyl dieselReference
Fuel tank39.7 LReference
Engine43.3 kWReference
SAME 1053PReference
dieselReference
3-cylinderReference
air-cooled inlineReference
Displacement3.1 LReference
Bore/Stroke105 x 120 mmReference
Power43.3 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronizedReference
14-speed creeperReference
TypesynchronizedReference
Gears8 forward and 4 reverseReference
Clutchmechanical dry discReference
Four gears (1-4) in two ranges (low/high) plus reverse range.Reference
TypecreeperReference
Gears14 forward and 7 reverseReference
PTO & Hydraulics
Pressure147.1 barReference
Valves1Reference
Pump flow24.0 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1819 kgReference
Rear PTOindependentReference
Clutchdry discReference
Rear PTO Type540 (1.375)Reference
Dimensions
2WD Wheelbase183 cmReference
4WD Wheelbase191 cmReference
Weight4056 to 4519 poundsReference
Front tire5.00-16Reference
2WD Rear tire11.2/10-28Reference
2WD Standard tires (ag)Front: 5.00-16. Rear: 11.2/10-28Reference
4WD Standard tires (ag)Front: 7.50-18. Rear: 12.4/11-28Reference
2WD Optional tires (ag)Front: 6.00-16. Rear: 12.4/11-28Reference
2WD Optional tires (ag)Front: 6.00-16. Rear: 13.6/12-28Reference
4WD Optional tires (ag)Front: 7.50-20. Rear: 13.6/12-28Reference
2WD Length303 cmReference
4WD Length305 cmReference
2WD Width107 cmReference
4WD Width118 cmReference
2WD Weight1839 kgReference
4WD Weight2049 kgReference
2WD Steering wheel140 cmReference
4WD Steering wheel147 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
SAME Vigneron 60 Height
2WD Hood124 cmReference
4WD Hood129 cmReference
Speeds
With 11.2/10-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
