Tractor · 1980Unverified
Satoh Beaver III S373
Satoh Beaver III S373 — Compact Utility tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
1124 to 1235 pounds
Hover a source tag to verify
Overview
ManufacturerSatohReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Engine
Mitsubishi 0.8L 3-cyl dieselReference
Fuel tank15.1 LReference
Engine12.3 kWReference
MitsubishiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Power12.3 kWReference
Compression23:1Reference
Rated RPM2700Reference
Starter volts12Reference
Oil capacity2.9 LReference
Coolant capacity4.9 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
Oil capacity12.0 LReference
PTO & Hydraulics
PTO (claimed)10.1 kWReference
Pump flow13.6 lpmReference
Rear TypeIReference
Controlnon-positional controlReference
Rear lift (at ends)650 kgReference
2WD Rear PTO50.4Reference
4WD Rear PTO51.2Reference
Rear PTO Type565/832/1364 (1.375)Reference
Dimensions
Weight1124 to 1235 poundsReference
Front tire4.00-9Reference
2WD Rear tire8-16Reference
2WD Standard tires (ag)Front: 4.00-9. Rear: 8-16Reference
4WD Standard tires (ag)Front: 5-12. Rear: 8-16Reference
2WD Lawn/turf front18x7.00-8Reference
4WD Lawn/turf front6-12Reference
Lawn/turf rear9.5-16Reference
2WD Length196 cmReference
4WD Length196 cmReference
Width96 cmReference
Height118 cmReference
2WD Weight509 kgReference
4WD Weight560 kgReference
2WD Ground clearance26 cmReference
4WD Ground clearance23 cmReference
2WD Front tread71 cmReference
4WD Front tread78 cmReference
Rear tread73/88 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH45Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
