Tractor · 1972Unverified
Satoh Elk S550
Satoh Elk S550 — Compact Utility tractor · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
648 kg
Hover a source tag to verify
Overview
ManufacturerSatohReference
Compact Utility tractorReference
Built in JapanReference
Two-wheel driveReference
Final drivesspur gearReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Engine
Mazda 1.0L 4-cyl gasolineReference
Fuel tank18.0 LReference
Engine12.7 kWReference
MazdaReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke68 x 68 mmReference
Power12.7 kWReference
Fuel systemcarburetorReference
Air cleanerdryReference
Compression8.5:1Reference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity3.0 LReference
Coolant capacity3.0 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity14.0 LReference
PTO & Hydraulics
PTO (claimed)11.6 kWReference
Rear TypeIReference
Rear lift499 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2120Reference
Dimensions
Wheelbase149 cmReference
Weight648 kgReference
Front tire4.00x12Reference
Rear tire8.3/8x24Reference
Ag front4.00x12Reference
Ag rear8.3/8x24Reference
Lawn/turf front20x8-10Reference
Lawn/turf rear13.6-16Reference
Length262 cmReference
Width114 cmReference
Height (steering wheel)131 cmReference
Ground clearance33 cmReference
Front tread96 to 101 cmReference
Rear tread95 to 104 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
