Tractor · 1977Unverified
Satoh ST-1300
Satoh ST-1300 — Compact Utility tractor · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
1157 to 1301 pounds
Hover a source tag to verify
Overview
ManufacturerSatohReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
ST1300D4WDReference
D1300similar Mitsubishi modelReference
Engine
Mitsubishi 0.7L 2-cyl dieselReference
Engine9.5 kWReference
Mitsubishi KE70Reference
dieselReference
2-cylinderReference
liquid-cooled inlineReference
Displacement0.7 LReference
Bore/Stroke73 x 80 mmReference
Power9.5 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Dimensions
2WD Wheelbase122 cmReference
4WD Wheelbase126 cmReference
Weight1157 to 1301 poundsReference
2WD Length188 cmReference
4WD Length194 cmReference
Width99 cmReference
2WD Height (steering wheel)112 cmReference
4WD Height (steering wheel)113 cmReference
2WD Weight524 kgReference
4WD Weight590 kgReference
2WD Ground clearance25 cmReference
4WD Ground clearance24 cmReference
2WD Front tread72 cmReference
4WD Front tread75 cmReference
Rear tread73/88 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
