The Schluter AS 22 is a tractor model rated at 22 hp — making it one of the more compact options in its class. The AS 22 was manufactured from 1953 to 1956. Under the hood is a 2-cylinder diesel liquid-cooled engine, driving through two-wheel drive with a 5-speed gearbox. Listed weight is 1619 kg, and it is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1619 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
22 hp
Recorded weight
1619 kg
Transmissions
5-speed gear
Production years
1953-1956
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Standard-tread tractorReference
Two-wheel driveReference
Open operator station.Reference
Engine
Schluter 2.4L 2-cyl dieselReference
Engine16.4 kWReference
SchluterReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke100 x 150 mmReference
Power16.4 kWReference
Air cleaneroil bathReference
Compression20:1Reference
Rated RPM1500Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
Dimensions
Wheelbase180 cmReference
Weight1619 kgReference
Front tire5.50-16Reference
Rear tire8-32Reference
Ag front5.50-16Reference
Ag rear8-32Reference
Length279 cmReference
Width157 cmReference
Height159 cmReference
Ground clearance40 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
