Tractor · 1984Unverified
Schluter Compact 1250 TV 6
Schluter Compact 1250 TV 6 · 120 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
120 hp
Weight
5120 kg
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Drum brakesReference
Engine
MAN 5.7L 6-cyl dieselReference
Fuel tank160.1 LReference
Engine89.5 kWReference
MAN D 0226 MTE 51Reference
turbocharged dieselReference
6-cylinderReference
Displacement5.7 LReference
Bore/Stroke102 x 116 mmReference
Power89.5 kWReference
Rated RPM2200Reference
Torque461.0 NmReference
Torque RPM1300Reference
Transmission
12-speedReference
Gears12 forward and 5 reverseReference
PTO & Hydraulics
Total flow54.9 lpmReference
Rear lift6201 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase243 cmReference
Weight5120 kgReference
Front tire14.9R28Reference
Rear tire18.4R38Reference
Ag front14.9R28Reference
Ag rear18.4R38Reference
Length421 cmReference
Height271 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
