Tractor · 1971Unverified
Schluter Compact 850
Schluter Compact 850 — Model year 1971-19741974-19781978-1983 · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
7574 to 8522 pounds
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Two- or four-wheel driveReference
Steeringmechanical/power assistReference
Drum brakesReference
Engine
Schluter 4.8L 4-cyl dieselReference
Fuel tank99.9 LReference
Engine59.7 kWReference
Schluter SDM 110 W 4Reference
dieselReference
4-cylinderReference
Displacement4.8 LReference
Bore/Stroke110 x 125 mmReference
Power59.7 kWReference
Rated RPM1800Reference
Torque343.1 NmReference
Torque RPM1300Reference
Transmission
12-speedReference
Gears12 forward and 6 reverseReference
PTO & Hydraulics
Rear lift3200 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase234 cmReference
Weight7574 to 8522 poundsReference
Front tire6.50-20Reference
Rear tire13.6-36Reference
Ag front6.50-20 (2WD)Reference
Ag front11.2-24 (4WD)Reference
Ag rear13.6-36Reference
Length394 cmReference
Height246 cmReference
Weight3435 kgReference
Weight3865 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
