Tractor · 1982Unverified
Schluter Compact 850 Special
Schluter Compact 850 Special · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Weight
4300 kg
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Four-wheel driveReference
Power steeringReference
Hydraulic drum brakesReference
Super Silent cab standard.Reference
Engine
Schluter 4.9L 4-cyl dieselReference
Fuel tank155.9 LReference
Engine67.1 kWReference
Schluter SDM 112 W 4Reference
dieselReference
4-cylinderReference
Displacement4.9 LReference
Bore/Stroke112 x 125 mmReference
Power67.1 kWReference
Rated RPM1800Reference
Torque373.0 NmReference
Torque RPM1300Reference
Transmission
12-speed synchromeshReference
TypesynchromeshReference
Gears12 forward and 6 reverseReference
PTO & Hydraulics
Total flow37.9 lpmReference
Rear lift3600 kgReference
Rear lift4500 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase234 cmReference
Weight4300 kgReference
Front tire14.9R24Reference
Rear tire18.4R38Reference
Ag front14.9R24Reference
Ag rear18.4R38Reference
Length411 cmReference
Height277 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
