The Schluter Profi-Trac 3500 TVL is a tractor with a rated output of 320 horsepower, positioning it among the more powerful machines in its class. It was manufactured between 1978 and 1981. The tractor is equipped with a 6-cylinder turbocharged diesel engine, which transmits power to all four wheels via an 18-speed gearbox. Its weight is listed at 12,252 kilograms.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
320 hp
Weight
12252 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
320 hp
Recorded weight
12252 kg
Transmissions
18-speed
Production years
1978-1981
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Four-wheel Drive (4WD) tractorReference
Drive4x4 4WDReference
Power four-wheel steeringReference
Dry disc brakesReference
standardReference
Engine
MAN 11.4L 6-cyl dieselReference
Fuel tank445.1 LReference
Engine238.6 kWReference
MAN D 2566 MTEReference
turbocharged dieselReference
6-cylinderReference
Displacement11.4 LReference
Bore/Stroke125 x 155 mmReference
Power238.6 kWReference
Rated RPM2200Reference
Torque1138.2 NmReference
Torque RPM1500Reference
Transmission
18-speedReference
Gears18 forward and 4 reverseReference
PTO & Hydraulics
Total flow53.0 lpmReference
Rear lift5801 kgReference
Rear lift8401 kgReference
Rear PTO Type1000Reference
Dimensions
Wheelbase289 cmReference
Weight12252 kgReference
Front tire20.8R38Reference
Rear tire20.8R38Reference
Ag front20.8R38Reference
Ag rear20.8R38Reference
Length614 cmReference
Height345 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
