Tractor · 1971Unverified
Schluter Super 1150
Schluter Super 1150 · 105 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
105 hp
Weight
9470 to 10397 pounds
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringpower assistReference
Drum brakesReference
Engine
6.9L 6-cylReference
Fuel tank124.9 LReference
Engine78.3 kWReference
SDM 108 W 6Reference
6-cylinderReference
Displacement6.9 LReference
Bore/Stroke108 x 125 mmReference
Power78.3 kWReference
Rated RPM1800Reference
Torque452.1 NmReference
Torque RPM1300Reference
Transmission
12-speedReference
Gears12 forward and 6 reverseReference
PTO & Hydraulics
Total flow26.1 lpmReference
Rear lift3200 kgReference
Rear lift4500 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase263 cmReference
Weight9470 to 10397 poundsReference
Front tire7.50-20Reference
Rear tire18.4-34Reference
Ag front7.50-20 (2WD)Reference
Ag front11.2-28 (4WD)Reference
Ag rear18.4-34Reference
Length438 cmReference
Height250 cmReference
Weight4295 kgReference
Weight4716 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
