The Schluter Super 1250V is a tractor rated at 115 horsepower, a mid-range figure for its class. It was produced between 1974 and 1976. Equipped with a 6-cylinder engine and four-wheel drive, the tractor features a hydrostatic transmission. Its operating weight is 5065 kg, making it suitable for operations of 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
115 hp
Weight
5065 kg
Catalogue coverage
Variants represented
2
Richest spec table
30 rows
Recorded power
115 hp
Recorded weight
5065 kg
Transmissions
12-speed
Production years
1974-1976
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Drum brakesReference
standardReference
Engine
7.1L 6-cylReference
Fuel tank124.9 LReference
Fuel tank260.0 LReference
Engine85.8 kWReference
SDM 110 W 6Reference
6-cylinderReference
Displacement7.1 LReference
Bore/Stroke110 x 125 mmReference
Power85.8 kWReference
Rated RPM1800Reference
Torque462.1 NmReference
Torque RPM1300Reference
Transmission
12-speedReference
Gears12 forward and 6 reverseReference
PTO & Hydraulics
Rear lift4500 kgReference
Rear lift5601 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase263 cmReference
Weight5065 kgReference
Front tire11.2-28Reference
Rear tire18.4-34Reference
Ag front11.2-28Reference
Ag rear18.4-34Reference
Length440 cmReference
Height265 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
