Tractor · 1988Unverified
Schluter Super 1900 TVL-LS Special
Schluter Super 1900 TVL-LS Special · 185 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
185 hp
Weight
6901 kg
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Drum brakesReference
standardReference
Engine
7.4L 6-cylReference
Fuel tank310.0 LReference
Engine138.0 kWReference
SDMT 112 W 6 LLKReference
intercooled turboReference
6-cylinderReference
Displacement7.4 LReference
Bore/Stroke112 x 125 mmReference
Power138.0 kWReference
Rated RPM2100Reference
Torque795.2 NmReference
Torque RPM1300Reference
Transmission
24-speedReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Total flow53.0 lpmReference
Rear lift6201 kgReference
Rear lift8401 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase280 cmReference
Weight6901 kgReference
Front tire16.9R28Reference
Rear tire20.8R38Reference
Ag front16.9R28Reference
Ag rear20.8R38Reference
Length475 cmReference
Height292 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
