Tractor · 1966Unverified
Schluter Super 900
Schluter Super 900 · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Weight
8820 to 9724 pounds
Hover a source tag to verify
Overview
ManufacturerSchluterReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringpower assistReference
Drum brakesReference
Engine
7.1L 6-cylReference
Fuel tank104.8 LReference
Engine67.1 kWReference
SD 110 W 6Reference
6-cylinderReference
Displacement7.1 LReference
Bore/Stroke108 x 125 mmReference
Power67.1 kWReference
Rated RPM1800Reference
Torque393.1 NmReference
Torque RPM1300Reference
Transmission
12-speedReference
Gears12 forward and 6 reverseReference
PTO & Hydraulics
Total flow26.1 lpmReference
Rear lift2650 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase262 cmReference
Weight8820 to 9724 poundsReference
Front tire6.50-20Reference
Rear tire18.4-30Reference
Ag front6.50-20 (2WD)Reference
Ag front11.2-24 (4WD)Reference
Ag rear18.4-30Reference
Length436 cmReference
Height169 cmReference
Weight4000 kgReference
Weight4410 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
