Lawn Tractor · 1999Unverified
Scotts S2046
Scotts S2046 — Lawn tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
184 kg
Hover a source tag to verify
Overview
DistributorScottsReference
ManufacturerJohn DeereReference
Lawn tractorReference
Built in Greeneville, Tennessee, USAReference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
20HP Briggs & Stratton 655cc 2-cyl gasolineReference
Fuel tank4.7 LReference
Briggs & StrattonReference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement40.0 ciReference
Power14.9 kWReference
Air cleanerfoamReference
StarterelectricReference
Starter volts12Reference
Sparkplug gap0.762 mmReference
Oil capacity1.9 LReference
Image courtesy of Douglas WardenskiReference
Transmission
hydrostaticReference
TransmissionTuff Torq K-51Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Weight184 kgReference
Front tire15x6.50-6Reference
Rear tire20x10.0-8Reference
Lawn/turf front15x6.50-6Reference
Lawn/turf rear20x10.0-8Reference
Length152 cmReference
Width96 cmReference
Height98 cmReference
Scotts S2046 attachments
46" mid-mount mower deckReference
snowblowerReference
bladeReference
S2046 Serial Number Location
Serial number plate on fender deck under seat.Reference
S2046 Serial Numbers
1999010001Reference
2000035001Reference
2001120001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery CCA190Reference
Battery volts12Reference
Battery GroupBCI Group U1Reference
Attachment overview
46" mid-mount mower deckReference
SnowblowerReference
BladeReference
46" Mower deck
Typemid-mount ScottsReference
Type3-bladeReference
Cutting width116 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
