The Sears 1030 502.25613 is a lawn tractor with an approximate power output of 10 hp, categorising it at the lower end of its class. It was manufactured in 1979. The model features a 1-cylinder petrol air-cooled engine and two-wheel drive, paired with a 5-speed gearbox. It has a listed operating weight of 149 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
149 kg
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
10 hp
Transmissions
5-speed gear
Production years
1979-1979
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorSearsReference
ManufacturerMurrayReference
Riding lawn mowerReference
Original price was $939 in 1979Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
10HP 1-cyl gasolineReference
Fuel tank2.8 LReference
gasolineReference
1-cylinderReference
air-cooledReference
Power7.5 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed gearReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
Dimensions
Weight149 kgReference
Front tire10.0x4Reference
Rear tire16.0x6.50Reference
Lawn/turf front10.0x4Reference
Lawn/turf rear16.0x6.50Reference
Length138 cmReference
Width88 cmReference
Height91 cmReference
Shipping weight149 kgReference
Sears 1030 attachments
30" mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging systemtrickle chargerReference
Charging amps1Reference
Battery volts12Reference
Battery AH14Reference
30" Mower deck
Typemid-mount SearsReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Overall width99 cmReference
Cut height3 to 8 cmReference
Cut positions7Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
