The Sears 10/4 502.25130 is a lawn tractor rated at 10 hp — making it one of the more compact options in its class. It was manufactured in 1977. It is powered by a 1-cylinder petrol air-cooled engine, driving through two-wheel drive with a 4-speed gearbox. Listed weight is 243 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
243 kg
Catalogue coverage
Variants represented
2
Richest spec table
45 rows
Recorded power
10 hp
Recorded weight
243 kg
Transmissions
4-speed gear
Production years
1977-1977
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorSearsReference
ManufacturerMurrayReference
Garden tractorReference
Original price was $989 in 1979Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
10HP Briggs & Stratton 1-cyl gasolineReference
Fuel tank2.8 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Power (gross)7.5 kWReference
Air cleanerfoam elementReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed gearReference
TransmissionPeerless 2300Reference
Typebelt-driven gearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
TypeSears 3-point hitchReference
Dimensions
Weight243 kgReference
Front tire16x5.5Reference
Rear tire22x7.50x12Reference
Weight37 kgReference
Lawn/turf front16x5.5Reference
Lawn/turf rear22x7.50x12Reference
Length166 cmReference
Width95 cmReference
Height90 cmReference
Shipping weight243 kgReference
Sears 10/4 attachments
42" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH30Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
42" Mower deck
Typemid-mount Sears 25137Reference
Type3-blade with manual liftReference
Cutting width106 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
